Technical specifications
9.1 General specifications
SIMATIC IPC MD-57A
Operating Instructions, 09/2023, A5E52775302-AA
85
Camera
Resolution
• RGB camera: 1280×720; 30 FPS
• Infrared sensor: 640×360; 30 FPS
WLAN and Bluetooth
WLAN is supported in the frequency ranges.
Bluetooth version
Standard 5.3
WiFi version
6E
WLAN standard according to IEEE standard
IEEE802.a/b/g/n/ac R2/ax R2 (pre-standard)
Frequency ranges
• 2.4 GHz
• 5.0 GHz
•
6.0 GHz
TX Frequency bands
Modes of Operation
Transmitter Frequency Range (MHz)
Output Power
2.4 GHz WLAN
2412 - 2462
20 dBm
5 GHz WLAN
5180 - 5825
20 dBm
6 GHz WLAN
5995 - 7115
13 dBm
Bluetooth
2402 - 2480
11.2 dBm
Connection range
Up to 100 m
Transmission rate
Up to 1.73 Gbps
Keyboard
Variant
Standard notebook
Key distance
19 mm
Key drop
2.0 mm
Pointing device integrated
Touchpad
Interfaces
RS232 interface (COM1)
• RS232 interface is integrated in every device as standard
9-pin socket, no electrical isolation r serial interface V.24
USB
• 1× USB 3.2; Gen. 1; type A
(left side of device): Max. 0.9 A
• 1× USB 3.2; Gen. 1; type A
(rights side of device): Max. 0.9 A
• 2× USB 3.2, Gen. 2x1; type A (right side of device):
Max. 0.9 A
• 2× USB4, Gen. 3; type C
(right side of device): Max. 3.0 A
15 W per 1×USB, 2×USB provide 22 W, battery or
mains operation makes no difference.
The total power of all USB ports and built-in expansion
modules (M.2) must not exceed 15 W in total. Read the
more detailed information in the section "USB socket with
charging function (Page 52)".
