Technical specifications
9
9.1 General specifications
Order nos.
See order documents or rating plate
Dimensions (W x H x D in mm)
• Display opened (90°): 386 × 300 × 281
•
Display closed (0°): 386 × 41 × 281
Weight
Approx. 2.8 kg
Supply voltage (UN)
100 V to 240 V AC (±10%); sinusoidal
Line voltage frequency
50 - 60 Hz (47 to 63 Hz)
Power consumption (AC)
• Operation
• In DeepSleep (power supply connected)
• In DeepSleep (battery operation)
• Approx. 263 W
• 0.25 W typical
• < 0.001 W typical
Max. current (100... 230 V AC)
Continuous current up to 3 A (during startup up to 174 A
for 0.7 ms)
Output voltage of the power supply unit
(DC)
19 V
Output current of the power supply unit
(DC)
Max. 12.63 A
Output power of power supply unit (DC)
Max. 240 W
Standby power (in battery operation)
Typically 1.5 W
Lithium polymer battery, 3S2P, 6x cells
with charge status detection
Min. 8010 mAh; 11.1 V; recyclable; up to 40
o
C high num-
ber of cycles in harsh environments; low self-discharge
Noise emission
< 45 dB(A) according to ISO 7779
Degree of protection (entire device)
IP 30 (with closed covers)
according to IEC 60529
Safety
Protection class
Safety class II according to IEC 61140
Safety specifications
• IEC 62368-1/EN 62368-1
• UL 62368-1 Third Edition
•
CAN/CSA C22.2 No. 62368-1-14 Third Edition
Electromagnetic compatibility (EMC)
Emitted interference
EN 61000-6-3
CAN/CSA CISPR32 Class B, EN 55032 Class B,
EN 61000-3-2 class D, EN 61000-3-3
Noise immunity:
Mains borne disturbance variables on sup-
ply lines
± 2 kV; (according to IEC 61000-4-4; Burst)
± 1 kV; (according to IEC 61000-4-5; Surge sym./line to line)
± 2 kV; (according to IEC 61000-4-5; Surge sym./
line to earth)
Noise immunity on signal lines
• ± 1 kV; (to IEC 61000-4-4; burst; length < 30 m)
• ± 2 kV; (to IEC 61000-4-4; burst; length > 30 m)
• ± 2 kV; (acc. to IEC 61000-4-5; surge pulse/
cable to ground; length > 30 m)
