Expanding and assigning parameters to the device
5.2 Installing a PCIe module
SIMATIC IPC227E
Operating Instructions, 11/2016, A5E35782395-AB
59
Turn the pressure piece on card
holder if necessary to adjust the
bracket to the height of the plug
-
in card.
Push the pressure piece against
the plug-in card
Tighten the screw
