Technical information
8.4 Technical specifications
SIMATIC IPC477E
130 Operating Instructions, 12/2016, A5E37455003-AB
Electromagnetic compatibility
Interference emission EN 61000-6-4; CISPR 22 Class A;
FCC Class A
Immunity with regard to conduct-
ed interference on the supply lines
± 2 kV according to IEC 61000-4-4; burst
± 1 kV according to IEC 61000-4-5; symmetrical surge
± 2 kV according to IEC 61000-4-5; asymmetrical surge
Noise immunity on signal lines ± 2 kV according to IEC 61000-4-4; Burst; Length > 3 m
± 1 kV according to IEC 61000-4-4; Burst; length < 3 m
± 2 kV according to IEC 61000-4-5; Surge, symmetric, length >
Immunity to electrostatic dis-
charge
± 6 KV contact discharge at the front according to IEC 61000-4-2
± 4 kV, housing contact discharge at the back according to
IEC 61000-4-2
± 8 kV air discharge according to IEC 61000-4-2
Immunity to RF interference 10 V/m, 80 to 2000 MHz
80% AM according to IEC 61000-4-3
3 V/m, 2 to 2.7 GHz
10 V, 10 kHz to 80 MHz according to IEC 61000-4-6
Immunity to magnetic fields
100 A/m, 50/60 Hz according to IEC 61000-4-8
Depending on the device variants, the device features the following components:
Processor
• Intel® Celeron® Processor G3902E
(2 MB cache, 1.6 GHz)
• Intel® Core™ i3-6102E Processor
(3 MB cache, 1.9 GHz)
• Intel® Core™ i5-6442EQ Processor
(6 MB cache, up to 2.7 GHz)
• Intel® Xeon® Processor E3-1505L v5
(8 MB cache, up to 2.8 GHz)
Main memory Memory modules without ECC:
• 4 GB DDR4-SDRAM SODIMM
• 8 GB DDR4-SDRAM SODIMM
• 16 GB DDR4-SDRAM SODIMM
Memory module with ECC (not combinable with i5 CPU):
• 8 GB DDR4-SDRAM SODIMM
• 16 GB DDR4 SDRAM SODIMM
1
1
For devices with retentivity
