Technical information
8.4 Technical specifications
SIMATIC IPC477E
Operating Instructions, 12/2016, A5E37455003-AB
131
Drive and memory media
Depending on the device variants, the device features the following components:
SATA drive 1 slot
Solid State Drive
2.5"; 80 GB / 240 GB, SATA
Hard disk drive, HDD 2.5", ≥ 320 GB, SATA
CFast card
• 2 GB optional or
• 4 GB optional or
• 8 GB optional or
• 16 GB optional or
• 30 GB optional
Display
15" (MT)
15"
1
19"
22"
Display type LCD TFT with
extended viewing
angle
LCD TFT with
extended viewing
angle
LCD TFT LCD TFT with
extended view-
ing angle
Active display area
344 x 194 mm
331 x 207 mm
410 x 230 mm
475 x 267 mm
Resolution 1366 x 768 pixels 1280 x 800 pixels 1366 x 768
pixels
1920 x 1080
pixels
Possible colors
Up to 16.7 million
Brightness control
Yes, from 0 to 99
2
, 0 = backlight off
Backlighting
Half Brightness Life
Time (MTBF
2 3
)
LED
50000 h
LED
50000 h
LED
50000 h
LED
30000 h
Pixel error class in ac-
cordance with
ISO 9241-307
II
Touch force resistive
touch screen
With test pen, 2 mm diameter: 5 N
Graphics
Graphics controller
Intel® HD Graphics 510 / 530 / P530 (depending on CPU type)
Graphics memory
32 to 512 MB shared memory
External interfaces DP (DisplayPort): 1920 × 1200, 60 Hz
1
resistive touch screen only
2
Via SetBrightness dialog: 9 to 99 (≙ 10 to 100%),
via SetBrightness command line call: 0 to 99
3
MTBF: Operating hours after which the maximum brightness is reduced by half compared to the
original value. MTBF is increased by using the integrated dimming function, for example, time-
controlled via screen saver or centrally via PROFIenergy.
