Technical specifications
14.1 General specifications
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
137
General specifications
RAM 2 DIMM base maximum 8 GB DDR3 with 1066 MT/sec
SDRAM (PC3-8500)
Modules with and without ECC can be operated
Memory configuration 1 GB to 8 GB DDR3 (PC3-8500), max. 3.5 GB can be used
for 32-bit operating system and applications. Modules with
and without ECC can be ordered.
(see ordering documents for features)
Free expansion slots max. three modules simultaneously, grouped as follows:
2x PCI; 1x PCIe x16 graphics (PEG)
or
1x PCI, 1x PCIe x4 (mech. PCIe x8), 1x PCIe x16 graphics
(PEG)
All modules up to 312 mm length are supported.
Max. permissible power consumption
per PCI slot
5 V/ 5 A or 3.3 V/ 7 A, 12 V/ 0.5 A, -12 V/ 0.05 A
Max. permissible power consumption
per PCIe slot
PCIe x4 module: 3.3 V/3A; 12 V/2.1 A, 3.3 Vaux/0.4 A
Max. permissible power consumption
per PCIe slot
PCIe x16 module: 3.3 V/3 A; 12 V/2.1 A, 3.3 Vaux/0.4 A
Max. permissible power loss per PCI
slot
Accumulated power loss (all voltages) may not exceed 25 W.
Max. permissible power loss at all
slots
Accumulated power loss (all slots) may not exceed 75 W.
Accumulated 3.3 Vuax current may not exceed 0.8 A.
Maximum bandwidth of PCI slots 133 MB/s bandwidth
Maximum bandwidth of PCIe slots 2.5 GB/s bandwidth per lane
Drives (for configuration details, refer to the order documentation)
Hard disk drive 3.5" SATA 300, 250 / 500 GB
NCQ (Native Command Queuing) is supported.
Flash memory 2.5" Solid State Disk
DVD burner Slimline SATA
Read:
DVD ROM: Single Layer 8x, Dual Layer 6x
DVD-R/+R: Single Layer 8x, Dual Layer 6x
DVD-RW/+RW 8x, DVD-RAM; 5x
CD-R 24x, CD-RW 24x
Write:
DVD+R 8x, DVD+RW 8x, DVD-R 8x, DVD-RW 6x
DVD+R9 (DL) 6x, DVD-R DL 2x
CD-R 24x, CD-RW 24x
CompactFlash drive Slot for Compact Flash card (behind the door, accessible from
the front)
Slot type II
Chipset
Main memory interface Max. 8 GB SDRAM DDR3 (PC3-8500), unbuffered, ECC, no
ECC
Module types: 1 Gbit or 2 Gbit technology x8 and x16
organized
