Technical specifications
14.1 General specifications
SIMATIC IPC647C
138 Operating Instructions, 12/2010, A5E02669337-02
General specifications
USB Max. 7 USB 2.0 devices (500 mA high current, high speed up
to 480 Mbps)
Max. accumulated power consumption of all USB devices: 2.3
A.
PCI/PCIe PCI V2.3, PCIe 2 data rate PCIe V1.0
SATA 6x SATA 150/300 with optional RAID
ATA n. a.
Graphics
Graphics controller Intel® HD Graphics Controller,
2-D and 3-D engine integrated in chipset, Gen. 5.75
Graphics memory Dynamic Video Memory Technology
(uses 32 MB to 1.7 GB RAM)
Resolutions/frequencies/colors
CRT (via DVI-I VGA adapter):
– Up to 1600x1200 at 120 Hz / 32-bit color depth
– Up to 2560x1600 at 60 Hz / 32-bit color depth
LCD via DVI-D:
– Up to 2048x1152 at 60 Hz / 32-bit color depth
Graphics module (optional)
Graphics card PCIe x16, Dual Head (2x DP, 2x VGA or
2x DVI-D)
Type: NVIDIA Quadro NVS 295 (256 MB graphics
memory)
Maximum resolution:
– DP 2560x1600 at 60 Hz / 32-bit color depth
– DVI 1920x1200 at 60 Hz / 32-bit color depth
– VGA 2048x1536 at 60 Hz / 32-bit color depth
Interfaces
COM1 Serial interface 1 (V.24), 9-pin D-sub connector
COM2 Serial interface 2 (V.24), 9-pin D-sub connector
LPT1 Parallel interface (Standard, EPP and ECP mode)
Connection for parallel interface printer
VGA (optional) (DVI-I) Connection of an analog monitor via DVI-I / VGA adapter
1x DVI-D For connecting a digital monitor
2x DP / DVI-D/VGA with Dual-Head
graphics controller (optional)
For connecting two digital or analog monitors DVI-D or VGA
via cable adapter
Keyboard PS/2 keyboard connection
Mouse PS/2 mouse connection
Rear of the device 4x USB 2.0 devices (500 mA high current, high speed up to
480 Mbps)
Front panel 2 x USB 2.0 devices (500 mA high current, high speed up to
480 Mbps)
USB
Internal 1 x USB 2.0 devices (500 mA high current, high speed up to
480 Mbps)
PROFIBUS (optional) 9-pin D–sub socket, CP5611-compatible, 9.6 Kbps to 12
Mbps, programmable with software
Electrically isolated RS485 (SELV circuit)*
PROFINET
4
) 3x RJ45 interface, CP 1616 compatible onboard interface
based on ERTEC 400, 10/100 Mbps electrically isolated *
