Installation, connecting up, commissioning
4.3 Installing, connecting up and commissioning
CP 1243-1 DNP3, CP 1243-1 IEC
30 Operating Instructions, 02/2014, C79000-G8976-C312-02
Table 4- 2 Procedure for installation and connecting up
Mount the CP on the DIN rail and connect it to
the module to its right.
Use a 35 mm DIN rail.
The slots to the left of the CPU are permitted.
Connect the Ethernet cable to the CP. You will find the pinout of the interface in the section Technical
specifications (Page 63).
Turn on the power supply.
The remaining steps in commissioning involve
downloading the STEP 7 project data.
The STEP 7 project data of the CP is transferred when you
load to the station. To load the station, connect the
engineering station on which the project data is located to the
Ethernet interface of the CPU.
You will find more detailed information on loading in the
following sections of the STEP 7 information system:
• "Loading project data"
• "Using online and diagnostics functions"
Close the front covers of the module and keep
them closed during operation.
