The slot time calculation takes into account only the optical network and the attachment of
nodes to the OLM in each case via a maximum 20 m long RS485 bus segment. Longer RS-
485 bus segments must be included by adding them to the Length
FOC
.
Note
If the slot time is configured with a value that is too low, this can lead to malfunctions and
error displays on the OLM. The system LED flashes red/green.
