Siemens SIMATIC NET User Manual

Optical link module
Operating Instructions, 01/2020, C79000-G8976-C270-06
73
Technical data
10
Properties
Device type
OLM P11 V4.1
OLM P12 V4.1
OLM P22 V4.1
OLM G11 V4.0
OLM G12 V4.0
OLM G22 V4.0
OLM G12-EEC V4.0
OLM G11-1300 V4.0
OLM G12-1300 V4.0
Power supply
Operating voltage 24 VDC safety extra-low voltage
Permitted voltage range 18..32 VDC NEC Class 2
Current consumption
Max. 200 mA
Output voltage for bus termination
RS-485 (D-sub female connector, pin 6)
5 VDC+5/-10%
Signaling contact
Function
Floating contact, opens if error/ fault occurs
Power CE: Max. 50 VDC/30 VAC safety extra-low voltage
cULus: Max. 30 VDC/30 VAC safety extra-low voltage
Current
Max. 1.0 A
Signal transmission
Transmission speed 9.6; 19.2; 45.45; 93.75; 187.5; 500 kbps
1.5; 3; 6; 12 Mbps
Transmission speed setting
Automatic
Bit error rate
<10
-9
Signal delay time (any input/output)
≤ 6.5 t
Bit
Retimer
Input (all channels)
Signal distortion
± 30%
Bit length
± 0,12%
Output (all channels) - average bit length
± 0,01%
Status signaling
Device
LED "System", red/green together with signaling contact
Electrical channels
LED yellow/red
Optical channels
LED yellow/red
Optical level
Level display with green/yellow/red LED
Safety
IEC standard
IEC 60950 (corresponds to EN 60950 and VDE 0805)
UL approval According to type plate
CSA approval According to type plate
C-Tick approval According to type plate
