Siemens SIMATIC NET User Manual

Technical data
Optical link module
74 Operating Instructions, 01/2020, C79000-G8976-C270-06
Properties
Device type
OLM P11 V4.1
OLM P12 V4.1
OLM P22 V4.1
OLM G11 V4.0
OLM G12 V4.0
OLM G22 V4.0
OLM G12-EEC V4.0
OLM G11-1300 V4.0
OLM G12-1300 V4.0
FM approval
According to type plate
Ex (hazardous area) approval
According to type plate
Electrical channels
Type
RS-485
Input dielectric strength
-7 V to +12 V
Optical channels
Wavelength
660 nm
860 nm
1310 nm
Launchable optical power
In glass fiber E 10/125 (9/125)
-
-
-19 dBm
In glass fiber G 50/125 Transmit power "re-
duced"
1
- -20.5 dBm -
Transmit power "De-
fault"
- -16 dBm -
In glass fiber G
62.5/125
Transmit power "re-
duced"
1
- -17.5 dBm -
Transmit power "De-
fault"
- -13 dBm -
IN PCF fiber S
200/230
Transmit power "re-
duced"
- - -
Transmit power "De-
fault"
-17 dBm - -
In plastic fiber S
980/1000
Transmit power "re-
duced"
-9.5 dBm - -
Transmit power "De-
fault"
-5 dBm - -
Sensitivity of receiver -23 dBm -28 dBm -29 dBm
Overdrive limit receiver (typical)
-7 dBm
-11 dBm
-14 dBm
Coverable distance
2
With glass fiber E 10/125 (9/125)
(0.5 dB/km)
- - 0 to 15 km
With glass fiber G
50/125
(3 dB/km @ 860 nm, 1
dB/km @ 1310 nm)
Transmit power "re-
duced"
1
- 0 to 1 km -
Transmit power "De-
fault"
- 0.5 to 3 km -
With glass fiber G
62.5/125
(3.5 dB/km @ 860 nm,
1 dB/km @ 1310 nm)
Transmit power "re-
duced"
1
- 0 to 1 km -
Transmit power "De-
fault"
- 0.5 to 3 km -
With PCF fiber S
200/230
Transmit power "re-
duced"
- - -
