Siemens SIMATIC NET User Manual

Technical data
Optical link module
Operating Instructions, 01/2020, C79000-G8976-C270-06
75
Properties
Device type
OLM P11 V4.1
OLM P12 V4.1
OLM P22 V4.1
OLM G11 V4.0
OLM G12 V4.0
OLM G22 V4.0
OLM G12-EEC V4.0
OLM G11-1300 V4.0
OLM G12-1300 V4.0
(10 dB/km)
Transmit power "De-
fault"
0 to 400 m - -
In plastic fiber S
980/1000
(0.2 dB/m)
Transmit power "re-
duced"
0 to 50 m - -
Transmit power "De-
fault"
30 to 80 m - -
Plug-in cable
BFOC/2.5
Electromagnetic compatibility
Radiated emission
EN 55022, limit class A
Conducted emission
EN 55022, limit class A
Electrostatic discharge (ESD)
EN 61000-4-2, ± 6 kV contact discharge
Radiated RF
EN 61000-4-3, 10 V/m 80 MHz..1 GHz
Conducted RF
EN 61000-4-6, 10 V 10 kHz .. 80 MHz
Burst
EN 61000-4-4, ± 2 kV on power supply, signaling contact and RS-485
Surge
(with Blitzductor)
EN 61000-4-5,
On power supply cables
On RS-485 bus cables
±1 kV balanced
±2 kV unbalanced
±2 kV unbalanced
Voltage interruptions
EN 61000-4-11
Voltage dips Voltage reduction by >95% for 5 s
Voltage reduction by 30% for 10 s
Voltage reduction by 60% for 100 ms and 1000 ms
Climatic environmental conditions
Ambient temperature during operation -25 °C to +60 °C for OLM G12-EEC
0 °C to +60 °C for all other OLMs
Storage and transportation temperature
-40 ℃ to +70 ℃
Relative humidity Max. 100%, condensing for OLM G12-EEC
<95%, non-condensing for all other OLMs
Mechanical environmental conditions
Oscillation in operation 10 to 58 Hz, 0.075 mm deflection
58 to 150 Hz, 1 g acceleration
Oscillation during transportation 5 Hz to 9 Hz, 3.5 mm deflection
9 Hz to 500 Hz, 1 g acceleration
Vibration during operation
40 m/s²
Shock in operation
150 m/s², 10 ms
Shock packed
250 m/s², 6 ms
Free fall unpacked
10 cm
Free fall packed 30 cm in product packaging
1 m in shipping packaging
