Siemens SIMATIC PN/M-Bus LINK User Manual

Technical specifications
12.1 Technical specifications
PN/M-Bus LINK
Operating Instructions, 03/2018, A5E44260928-AA
51
Article number
6BK1622-0AA00-0AA0
Interfaces
PROFINET IO
• automatic detection of transmission rate
No
• Transmission rate, max.
100 Mbit/s
• Number of RJ45 ports
2
• Number of FC (FastConnect) connections
2
PROFINET functions
• Assignment of the IP address, supported
Yes
• Assignment of the device name, supported
Yes
M-Bus
• Bus voltage, typ.
36 V
• Transmission rate, min.
300 bit/s
• Transmission rate, max.
9 600 bit/s
• Number of slaves, max.
40
• Short-circuit detection
Yes
• short-circuit proof
Yes
• Connectable conductor cross-section
1.5 mm²
• Cable length, max.
300 m
1. Interface
Interface type M-Bus master
Physics
3-wire screw-type terminal
Isolated
No
Interface types
• Number of ports
1
2. Interface
Interface type
PROFINET
Physics
Ethernet, 2-port switch, 2*RJ45
Isolated
Yes; 1 500 V AC or 2 250 V DC
Interface types
• Number of ports
2
• integrated switch
Yes
Functionality
• PROFINET IO Device
Yes
Isochronous mode
Isochronous operation (application synchro-
nized up to terminal)
No
