Siemens SIMATIC PN/M-Bus LINK User Manual

PN/M-Bus LINK
Operating Instructions, 03/2018, A5E44260928-AA
50
Technical specifications
12
12.1
Technical specifications
PN/M-Bus LINK
Article number
6BK1622-0AA00-0AA0
General information
Product type designation PN/M-Bus LINK
Firmware version
• FW update possible
Yes
Product function
• I&M data
Yes
Engineering with
• STEP 7 TIA Portal configurable/integrated
as of version
STEP 7 V15 or higher
Installation type/mounting
Mounting
DIN rail, wall mounting, portrait mounting
Mounting position
Any
Recommended mounting position
Horizontal
Supply voltage
Type of supply voltage
24 V DC
Rated value (DC)
24 V
permissible range, lower limit (DC)
20.4 V
permissible range, upper limit (DC)
28.8 V
Reverse polarity protection
Yes
Overvoltage protection
Yes
Short-circuit protection
Yes
Mains buffering
• Mains/voltage failure stored energy time
10 ms; PN side
Input current
Current consumption (rated value)
0.11 A; At 24 V and 5 loads
Current consumption, max. 0.4 A; At 20.4 V,
40 loads + 100 mA short-circuit current
Power loss
Power loss, typ.
2.4 W
