Technical Specifications S5-115F Manual
IM 314 Interface Module (6ES5 314-3UA11)
Technical Specifications
Current consumption (at 5 V) max. 1.0 A
Weight approx. 0.3 kg
(0.7 lb.)
Accessories
Adapter casing 6ES5 491-0LB11
Termination connector
for IM 314 6ES5 760-1AA11
721 connecting cable
( Catalog ST 52.3)
The IM 314 interface module is used in combination with the IM 304 interface module for
distributed connection (up to 600 m, or 1969 ft.) of expansion units (EUs) to a central con-
troller (CC). ( also Chapter 3).
IM 314
OUT
IN
SIEMENS SIMATIC 6ES5 314-3UA11 I1I2I3I4I5I6I7I8I9I10I
8-40 EWA 4NEB 811 6148-02
