Installation
2.2 Dimensions and guidelines
Getting started with S7-1200
26 Getting Started, 11/2009, A5E02486791-01
2.2 Dimensions and guidelines
PP
PPPP
PP
PP
① Thermal clearance: 25 mm
Always consider the following guidelines when planning your
installation:
Separate the devices from heat, high voltage, and electrical
noise.
Provide adequate clearance for cooling and wiring. A 25 mm
thermal zone must be provided above and below the unit for free
air circulation.
Refer to the
S7-1200 Programmable Controller System Manual
for
specific requirements and guidelines for installation.
WARNING
Installation or removal of S7-1200 or related equipment with the power applied could cause
electric shock or unexpected operation of equipment.
Failure to disable all power to the S7-1200 and related equipment during installation or
removal procedures could result in death, severe personal injury and/or property damage
due to electric shock or unexpected equipment operation.
Always follow appropriate safety precautions and ensure that power to the S7-1200 is
disabled before attempting to install or remove S7-1200 CPUs or related equipment.
