Getting started with S7-1200
Getting Started, 11/2009, A5E02486791-01
41
Complete the user program
4
In the next exercise, you will
complete the user program to
include the rest of the circuit by
inserting an on-delay timer and an
off-delay timer.
.
7'5
7'5
7'5
3%
3%
.
.
7'5
0
Note
S7-1200 does not limit the number of timers or counters in your user program. The data for
each timer is stored in a data block, so you are limited only by the size of your user program
in relation to the amount of load memory for your CPU.
