Siemens SIMATIC S7-1200

Getting started with S7-1200
Getting Started, 11/2009, A5E02486791-01
3
Preface
As part of the SIMATIC commitment to "totally
integrated automation" (TIA), the S7-1200 product
family and the STEP 7 Basic programming package
give you the tools for creating your automation
application. The compact design, low cost, and powerful
features make the S7-1200 compact controller a perfect
solution for controlling small applications.
The examples in this document guide your first steps in
the world of S7-1200, teaching you the basic skills
within the shortest possible time.
Note
Review the
S7-1200 Programmable Controller System Manual for safety guidelines
This quick-start guide provides only a quick introduction to the world of S7-1200. Before
performing the exercises in this quick-start guide, review the safety guidelines and other
information in the
SIMATIC S7-1200 Programmable Controller System Manual .
Parts list
Description Quantity Order number
CPU 1212C AC/DC/RLY 1 6ES7212-1BD30-0XB0
Simulator: SIM 1274 (digital inputs) 1 6ES7274-1XF30-0XA0
Standard Ethernet CAT5 cable 1 6XV1850-2GH20
STEP 7 Basic programming software 1 6ES7822 -0AA00-0YA0
The starter kit also contains the S7-1200 documentation collection CD.
Note
You must provide a power cord for the CPU.
The CPU 1212C AC/DC/RLY requires 120/240 VAC. You must provide a power cord and
connect it to the CPU. For any other CPU, refer to the
S7-1200 Programmable Controller
System Manual
for power requirements and installation procedures.
