Mechanical setup of the example station
4.1 Mounting the example station
SM331; AI 8x12 Bit Getting Started part 1: 4 -20mA
4-2 Getting Started, 11/2006, A5E00253410-02
step Graphic controller Description
3
Mounting the power supply:
• Hang the power supply on to the top end of the rail
• Screw it tight to the rail underneath
4
Connect the bus connector (delivered with the SM331) to
the left connector on the back of the CPU
5
Mounting the CPU:
• Hang the CPU on to the top end of the rail
• Push it all the way left to the power supply
• Push it down
• Screw it tight to the rail underneath
