SM331; AI 8x12 Bit Getting Started part 1: 4 -20mA
Getting Started, 11/2006, A5E00253410-02
2-1
Requirements
2
2.1 Basics
Basic Knowledge Required
No special knowledge of the field of automation technology is required in order to understand
the Getting Started guide. As the configuration of the analog module is done with the
software STEP7, proficiency in STEP7 would be advantageous.
Further information on STEP7 can be found in the electronic manuals that are supplied with
STEP7.
You will also need to know how to use computers or PC-like equipment (such as
programming devices) under Windows 95/98/2000/NT or XP.
Required hardware and software
The scope of delivery of the analog module consists of 2 parts:
● The module itself
● A front connector, which enables you to conveniently connect the power supply and the
data cables.
Analog module components
Quantity Article Order number
1 SM 331, Electrically ISOLATED 8 AI, ALARM DIAGNOSTICS 6ES7331-7KF02-0AB0
1 20-pin FRONT CONNECTOR with spring contacts 6ES7392-1BJ00-0AA0
The general SIMATIC components required for the example are as follows:
SIMATIC components of the example station
Quantity Article Order number
1 PS 307 Power Supply AC 120/230V, DC 24V, 5A 6ES7307-1EA00-0AA0
1 CPU 315-2 DP 6ES7315-2AG10-0AB0
1 MICRO MEMORY CARD, NFLASH, 4 MB 6ES7953-8LM00-0AA0
1 SIMATIC S7-300, RAIL L=530MM 6ES7390-1AF30-0AA0
1 Programming device (PD) with MPI interface and MPI cable
PC with corresponding interface card
depending on the
configuration
