Configuration of the SIMATIC Manager
6.3 STEP 7 user program
SM331; AI 8x12 Bit Getting Started part 1: 4 -20mA
6-20 Getting Started, 11/2006, A5E00253410-02
In the "Insert external source" dialog browse for the source file GSSM331T1DE.AWL, which
you have already downloaded and saved on your hard disk.
Select the source file GSSM331T1DE.AWL (red arrow).
Figure 6-15 Importing an external source
