Technical data
10.6 Mounting positions
BA 2030
Operating Instructions, 02/2021, A5E37880173A/RS-AM
123
Figure 10-16 Mounting positions for helical gearbox DF/ZF flange-mounted design and DZ/ZZ with
housing flange, size 39
