WARNING
Danger if the machine falls
The lifting lugs on the machine are designed only for the weight of the machine. If a machine
set is lifted and transported on a single machine, this can lead to mechanical failure of the
lifting lug. The machine or machine set may fall. This can result in death, serious injury or
material damage.
● Do not lift machine sets by attaching lifting tackle to the individual machines.
● Use only the equipment provided, e.g. the openings or lugs on the base plates, for
transporting machine sets. Note the maximum capacity of the lifting lug.
4.13.5 Lifting and transportation
● Persons driving cranes and fork-lift trucks must hold appropriate licenses.
● If the motor is packed, depending on the weight, size and on-site conditions, lift crates and
transport frames using a fork-lift truck or a crane with slings. Use a crane or fork-lift truck
suitable for the load.
● When lifting the machine, use only approved and undamaged sling guides and spreaders
of sufficient rated capacity. Check this equipment before using it. The weight of the machine
is shown on the rating plate.
● If adapter flange and adapter plates are also supplied, then lift them and transport these
parts separately. The load suspension equipment for the motor is not rated for lifting the
motor with mounted adapter flange is or adapter plates
Preparations for use
4.13 Transport and storage
SIMOTICS HV C 1NB1402-2AA84-4CA0-Z
Operating Instructions 06/2018 29
