● Check that the maximum permissible clamping thickness of 10 mm for the cable lug or strap
is not exceeded.
● Fasten the clamping screw according to the following table. Screw-in depth and tightening
torque are different depending on whether cable lugs or ground terminals are used.
Screw Screw-in depth Tightening torque
M12 x 25 > 16 mm 38 Nm
M16 x 35 > 20 mm 92 Nm
Tightening torque of bolts with cable lugs
Screw Screw-in depth Tightening torque
M6 > 9 mm 8 Nm
M8 > 12 mm 20 Nm
M10 > 15 mm 40 Nm
Tightening torque of bolts with ground terminals
6.3 Inserting and routing the cables
6.3.1 Connecting the machine for a specific direction of rotation
The technical data stipulate the following with respect to the motor connection:
● Direction of rotation
● The number and arrangement of the terminal boxes
● The circuit and connection of the motor winding
Electrical connection
6.3 Inserting and routing the cables
SIMOTICS HV C 1NB1402-2AA84-4CA0-Z
60 Operating Instructions 06/2018
