5.2.3 Removing the rotor shipping brace
If a rotor shipping brace is attached to the machine, remove it at the last possible moment,
for example, when you are ready to push on the output or drive element.
Note
Machines with an oil-injection interference fit and a center hole ≥ M56
An adapter is installed between the shaft and the rotor shipping brace on machines with an oil-
injection interference fit and a center hole ≥ M56. Remove this adapter together with the rotor
shipping brace.
See also
Securing the rotor (Page 31)
NOTICE
Removing the rotor shipping brace in the horizontal position.
Dismantling the rotor shipping brace when the machine is in a horizontal position could
damage the bearings.
● Only remove the rotor shipping brace when the machine is in a vertical position.
NOTICE
Turning the motor over without rotor shipping brace
Failure to fit the rotor shipping brace can result in damage to the bearings while the machine
is being turned onto its side.
● Fix the rotor in place before you turn the machine into a horizontal position.
See also
Securing the rotor (Page 31)
Assembly
5.2 Lift the machine to where it will be installed, and position it
SIMOTICS HV C 1NB1402-2AA84-4CA0-Z
46 Operating Instructions 06/2018
