5.2 Lift the machine to where it will be installed, and position it
5.2.1 Checking the load handling attachments
Inspect the load handling attachments such as the load trestles, lifting eyes and ring bolts and
also the lifting gear, before lifting the machine:
● Inspect the load handling attachments on the machine for possible damage. Replace any
load suspension equipment that is found to be damaged.
● Before use, check that the load suspension equipment is correctly attached.
● When lifting the machine, use only approved and undamaged lifting gear of sufficient rated
capacity. Check the lifting gear prior to its use.
WARNING
The machine can be dropped
If the load handling attachments and lifting gear are damaged or not correctly secured,
the machine may be dropped during lifting. This can result in death, serious injury or
material damage.
● Inspect the load handling attachments and lifting gear before use.
5.2.2 Preconditions for correct alignment and secure attachment
To align the machine correctly and fasten it securely, you require detailed specialist knowledge
of the following necessary measures:
● Preparing the foundation
● Select and mount the coupling
● Measure the radial and axial eccentricity
● Position the machine
If you are not familiar with the prescribed measures and procedures, make use of the services
offered by the Service Center (Page 111).
Assembly
5.2 Lift the machine to where it will be installed, and position it
SIMOTICS HV C 1NB1402-2AA84-4CA0-Z
Operating Instructions 06/2018 45
