Electrical connection
8.3 System integration
S-1FT7 synchronous motors
Configuration Manual, 09/2018, A5E45099423B AA
381
Power connection via terminal box
For electrical connection of the 1FT7, the following terminal boxes can be used for larger
shaft heights:
1FT7085
1FT7087
1FT7105
This terminal box is only available for motors of
shaft height 1FT713 with connector size 3.
Information on connecting
● Use cable lugs according to DIN 46234 for connection.
● First connect the protective conductor.
● Implement the terminal assignment in the terminal box as shown in the diagram.
● Connect the brake if there is one.
