Configuring drive-related I/Os (without symbolic
assignment)
A
A.1 Overview
The configuration of local measuring inputs is fundamentally different to the configuration of
global measuring inputs.
The assignment of the local measuring inputs is permanently related to the hardware of the
control unit and is performed
●
On the drive side via the drive expert list and
● During the configuration of the TO measuringInput via the measuring input number.
Local and global measuring inputs have different properties. Detailed information concerning
the differences can be found in Section Local and global measuring inputs (Page 318).
Information about the configuration can be found
● for global measuring inputs (with symbolic assignment) in Section Configuring global
measuring inputs (Page 211)
● for local measuring inputs in the appendix, in Section Configuring local measuring inputs
(Page 320).
Additional references
Further information and programming examples for configuring drive-related I/Os without
symbolic assignment can be found
● at Internet address (
http://support.automation.siemens.com/WW/view/en/29063656)
●
in the SIMOTION Utilities & Applications
SIMOTION Utilities & Applications is part of the scope of delivery of SIMOTION SCOUT.
