Commissioning 04/2005
SINAMICS G110 Operating Instructions
48 6SL3298-0AA11-0BP0
Flow chart Quick Commissioning (Level 1 Only – P0003=1)
P1120 Ramp-Up Time
Acceptable Range: 0 - 650 s
Time taken for the motor to accelerate from standstill up to
maximum motor frequency.
P1121 Ramp-Down Time
Acceptable Range: 0 - 650 s
Time taken for motor to decelerate from maximum motor
frequency down to standstill
P1000 Selection of Frequency Setpoint
2
1 = BOP frequency control
2 = Analogue Setpoint (Analog variant only)
3 = Fixed frequencies
5 = USS Interface (USS variant only)
P0010 Start Quick Commissioning
0 = Ready to Run
1 = Quick Commissioning (Recommended)
30 = Factory Setting
Note
Quick Commissioning must be started with P0010=1
and must be finished with P3900≠0. This ensures that
after quick commissioning P0010 will be set back to 0,
which is essential for motor operation.
P0100 Operation for Europe/N. America
0 = Power in kW; f default 50 Hz
1 = Power in hp; f default 60 Hz
2 = Power in kW; f default 60 Hz
Note
The position of the DIP switch (50/60 Hz) must be in
line with the setting of P0100 (0 or 1)
P0304 Rated Motor Voltage
1
Acceptable Range: 10 - 2000 V
Nominal motor voltage (V) from motor rating plate
P0305 Rated Motor Current
1
Acceptable Range: 0 - 2 x inverter rated current (A)
Nominal motor current (A) from motor rating plate
P0307 Rated Motor Power
1
Acceptable Range: 0.12 - 3.0 kW (0.16 - 4.02 hp)
Nominal motor power (kW) from motor rating plate.
If P0100 = 1, values will be in hp
P0310 Rated Motor Frequency
1
Acceptable Range: 12 - 650 Hz
Nominal motor frequency (Hz) from motor rating plate
P0311 Rated Motor Speed
1
Acceptable Range: 0 - 40000 min
-1
Nominal motor speed (rpm) from motor rating plate
P0700 Selection of Command Source
2
(on / off / reverse)
1 = Basic Operator Panel (BOP)
2 = Terminal / Digital Inputs
5 = USS Interface (USS variant only)
P1080 Min. Motor Frequency
Sets minimum motor frequency (0-650Hz) at which the
motor will run irrespective of the frequency setpoint. The
value set here is valid for both clockwise and anti-clockwise
rotation
P1082 Max. Motor Frequency
Sets maximum motor frequency (0-650Hz) at which the
motor will run at irrespective of the frequency setpoint. The
value set here is valid for both clockwise and anti-clockwise
rotation
1. Motor related parameters - please refer to the motor rating plate.
2. Denotes parameters that contain more detailed lists of possible settings for use in specific applications. Please refer to the
Parameter List.
P3900 End Quick Commissioning
0 = No Quick Commissioning (no motor calculation).
1 = End Quick Commissioning, with factory reset of all
other settings (Recommended)
2 = End Quick Commissioning, with factory reset of I/O
settings.
3 = End Quick Commissioning, without reset of all other
settings.
To Next Page
