flow speeds inside the hood without taking into account other cabinet internals such as additional electronic boards,
busbars and fuses. If several devices are installed in one cabinet, the required volumetric flow rate corresponds to
the sum of the flow rates required for the individual components. If multiple hoods are interconnected, the total
volumetric flow rate must be calculated as well and a suitable fan selected accordingly.
Output
power
[ kW ]
Frame
size
Rated
output current
[ A ]
Required volumetric flow rate
dV/dt of hood fan
[ m
3
/ s ]
Average flow speed
[ m / s ]
Power Modules / 380 V – 480 V 3AC
110
FL 210 (AC) 0.003 0.01
132
FL 260 (AC) 0.003 0.02
160
GL 310 (AC) 0.004 0.02
250
GL 490 (AC) 0.006 0.03
Basic Line Modules / 380 V – 480 V 3AC
360
FBL 740 (DC) 0.010 0.05
600
FBL 1220 (DC) 0.017 0.09
830
GBL 1730 (DC) 0.024 0.12
Basic Line Modules / 500 V – 690 V 3AC
355
FBL 420 (DC) 0.009 0.05
630
FBL 730 (DC) 0.016 0.08
1100
GBL 1300 (DC) 0.018 0.09
1370
GBL 1650 (DC) 0.023 0.12
Active Line Modules / 380 V – 480 V 3AC
300
GXL 549 (DC) 0.006 0.03
380
HXL 677 (DC) 0.007 0.04
500
HXL 941 (DC) 0.010 0.05
630
JXL 1100 (DC) 0.020 0.10
900
JXL 1573 (DC) 0.026 0.14
Active Line Modules / 500 V – 690 V 3AC
630
HXL 644 (DC) 0.007 0.04
800
HXL 823 (DC) 0.018 0.10
900
HXL 907 (DC) 0.018 0.10
1100
JXL 1147 (DC) 0.021 0.11
1400
JXL 1422 (DC) 0.024 0.12
1700
JXL 1740 (DC) 0.038 0.21
Motor Modules / 380 V – 480 V 3AC / 510 V – 720 V DC
110
FXL 210 (AC) 0.002 0.01
132
FXL 260 (AC) 0.003 0.02
160
GXL 310 (AC) 0.004 0.02
250
GXL 490 (AC) 0.006 0.03
315
HXL 605 (AC) 0.007 0.04
400
HXL 745 (AC) 0.009 0.05
450
HXL 840 (AC) 0.010 0.05
560
JXL 985 (AC) 0.020 0.10
710
JXL 1260 (AC) 0.024 0.12
800
JXL 1330 (AC) 0.026 0.14
800
JXL 1405 (AC) 0.026 0.14
Motor Modules / 500 V – 690 V 3AC / 675 V – 1035 V DC
90
FXL 100 (AC) 0.002 0.01
132
FXL 150 (AC) 0.003 0.02
200
GXL 215 (AC) 0.004 0.02
315
GXL 330 (AC) 0.005 0.03
450
HXL 465 (AC) 0.006 0.04
560
HXL 575 (AC) 0.007 0.04
710
HXL 735 (AC) 0.018 0.10
800
HXL 810 (AC) 0.018 0.10
800
JXL 810 (AC) 0.019 0.10
1000
JXL 1025 (AC) 0.021 0.11
1200
JXL 1270 (AC) 0.024 0.12
1500
JXL 1560 (AC) 0.038 0.21
Required volumetric flow rates dV/dt of hood-mounted fan in cabinets with degree of protection of > IP21
Fan type W2E200-HH38-01 supplied by EBM-Papst is recommended for use as a hood-mounted fan.
