Installing the Control System
SINUMERIK 802C base line
2-5
Start-Up
z
X20 digital inputs (DI)
10-pin front connector for connecting the NC READY relay
DI/O
z
X100 to X105
10-pin front connector for connecting digital inputs
z
X200 and X201
10-pin front connector for connecting digital outputs
Operating elements
Start-up switch S3
Fuse
Fuse F1, externally designed to allow users for convenient replacement.
S2 and D15
These elements are provided only for debugging internally.
