Gear stage 1: Motor/spindle = 2.5/1
Gear stage 2: Motor/spindle = 1/1
Gear stage 1
360 degrees MD 31080 MD 31050
Internal resolution = ------------------------- x -------------------------- x ------------------- x 1000incr/deg
MD 31020 x 4 MD 31070 MD 31060
360 1 1
Internal resolution = ----------------- x ------------- x ------------ x 1000pulses/deg = 17.5781
4 x 2048 1 2.5
One encoder increment corresponds to 17.5781 internal increments. One
encoder increment corresponds to 0.0175781 degrees (minimum positioning
step).
Gear stage 2
360 degrees MD 31080 MD 31050
Internal resolution = ------------------------- x -------------------------- x ------------------- x 1000incr/deg
MD 31020 x 4 MD 31070 MD 31060
360 1 1
Internal resolution = ----------------- x ------------- x ------------ x 1000pulses/deg = 43.945
4 x 2048 1 1
One encoder increment corresponds to 43.945 internal increments. One
encoder increment corresponds to 0.043945 degrees (minimum positioning
step).
Machine data default settings for analog motor axes
The machine data list below contains the default machine data with their
recommended settings with the analog motor axes connected.
After they have been set, the axis are ready to be traversed, as far as the
machine data are concerned, and only fine settings have to be done.
Number Description
Default
Value
Setting or
Remark
30130 Output type of setpoint
(setpoint branch): 0
01
30240 Type of actual value acquisition (actual
position value) (encoder no.)
0: Simulation
2: Encoder external
02
31020 Encoder markings per revolution
(encoder no.)
2048 Steps per
encoder
revolution
31030 Pitch of leadscrew 10 Leadscrew
pitch
31050 Denominator load gearbox
(control parameter no.): 0...5
1 Load gear
transmission
ratios
31060 Nominator load gearbox
(control parameter no.) 0...5
1 Load gear
transmission
ratios
(MD31080:MD
31050)
31070 Denominator resolver gearbox
(control parameter no.): 0...5
1 Load gear
transmission
ratios
