Siemens SINUMERIK 802C base line User Manual

Technical Appendix
SINUMERIK 802C base line
6-7
Start-Up
31030 LEADSCREW_PITCH
mm Pitch of leadscrew POWER ON
_always 10.0 0.0 plus DOUBLE 2/7
31040 ENC_IS_DIRECT
– Encoder mounted directly to the machine (encoder no:) POWER ON
_always 0 *** ***
BOOLEAN
2/7
31050 DRIVE_AX_RATIO_DENOM
– Denominator load gearbox (control parameter no.): 0...5 POWER ON
_always 1, 1, 1, 1, 1, 1 1 2147000000 DWORD 2/7
31060 DRIVE_AX_RATIO_NUMERA
– Numerator load gearbox (control parameter set no.): 0...5 POWER ON
_always 1, 1, 1, 1, 1, 1 1 2147000000 DWORD 2/7
31070 DRIVE_ENC_RATIO_DENOM
– Denominator resolver gearbox (encoder no.) POWER ON
_always 1 1 2147000000 DWORD 2/7
31080 DRIVE_ENC_RATIO_NUMERA
– Numerator resolver gearbox (encoder no.) POWER ON
_always 1 1 2147000000 DWORD 2/7
31090 JOG_INCR_WEIGHT
mm,
degrees
Evaluation of an increment with INC/handwheel RESET
32000 MAX_AX_VELO
mm/min,
rev/min
Maximum axis velocity NEW CONF
_always 10000. 0.0 plus DOUBLE 2/7
32010 JOG_VELO_RAPID
mm/min,
rev/min
Rapid treverse in jog mode RESET
_always 10000. 0.0 plus DOUBLE 2/7
32020 JOG_VELO
mm/min,
rev/min
Jog axis velocity RESET
_always 2000. 0.0 plus DOUBLE 2/7
32070 CORR_VELO
% Axis velocity for handwheel override, ext. ZO, cont.
dressing, distance control
RESET
_always 50 0.0 plus DWORD 2/7
