3. Execute/Correct Program 09.01
3-22 © Siemens AG, 2001. All rights reserved
SINUMERIK 802D Milling ISO Dialect M (ISF) - Edition 09.01
Block Search
Prerequisite:
Program is selected in "Automatic" and is being executed.
Interrupt program
Block
search
Select Block search
Program
level +
Program
level -
Possibly select the program
level higher or lower.
Select the block in the editor
with the cursor or
Search
OK
enter search text and start
search.
Enter changes
You have 4 possibilities for
repositioning:
On
contour
• At the start of the contour
On
end pt.
• At the end of the contour
Without
calculation
• Without using the tool
offsets
Interrupt
• At the interrupt point
Continue the program with
NC start.
Notice
Tool changes are only taken into consideration when the
tool is entered in the target block.
