Siemens SINUMERIK 802D Short Guide

09.01 8. Appendix
© Siemens AG, 2001. All rights reserved
8-45
SINUMERIK 802D Milling ISO Dialect M (ISF) - Edition 09.01
List of the G Functions
G code Function M/S
2)
Initial
setting
1)
Group
G0 Rapid traverse M X 1
G1 Linear interpolation M 1
G2 Circular interpolation in clockwise direction M 1
G3 Circular interpolation in counterclockwise
direction
M 1
G4
*)
Dwell time S 18
G9 Blockwise exact stop S 18
G10
*)
Load zero offset/tool offset M 18
G11
*)
End loading of zero offset/tool offset M 18
G15 Polar coordinate programming OFF M X 17
G16 Polar coordinate programming ON M 17
G17 Select machining plane X/Y M X 2
G18 Select machining plane Z/X M 2
G19 Select machining plane Y/Z M 2
G20 (70)
*)
Input system in inches M X 6
G21 (71)
*)
Metric input system M 6
G28
*)
Reference point S 18
G30
*)
approach 2nd, 3rd, 4th ref. pt. S 18
G31
*)
Measure using switching pushbutton M 18
G40 Tool radius offset OFF M X 7
G41 Tool radius offset to the left of the contour ON M 7
G42 Tool radius offset to the right of the contour
ON
M7
G43
*)
Tool length offset positive ON M 8
G44
*)
Tool length offset negative ON M 8
G49
*)
Tool length offset OFF M X 8
G52
*)
Select additive zero offset M 18
G53
*)
Approach position in the machine coordinate
system
S18
G54 Select 1st zero offset M X 14
G55 Select 2nd zero offset M 14
G56 Select 3rd zero offset M 14
G57 Select 4th zero offset M 14
