Siemens SINUMERIK 802D Short Guide

8. Appendix 09.01
8-46 © Siemens AG, 2001. All rights reserved
SINUMERIK 802D Milling ISO Dialect M (ISF) - Edition 09.01
List of the G Functions
G code Function M/S
2)
Initial
setting
1)
Group
G58 Select 5th zero offset M 14
G59 Select 6th zero offset M 14
G61 Exact stop S 15
G63
*)
Tapping M 15
G64 Continuous-path mode M X 15
G73
*)
Deep-hole drilling with chip breakage M 18
G74 Tapping left-hand thread M 18
G76
*)
Fine drilling M 18
G80
*)
Cycle OFF M X 9
G81
*)
Drill counterbores M 9
G82
*)
Drill countersinks M 9
G83
*)
Deep-hole drilling with chip removal M 9
G84 Tapping right-hand thread M 9
G85
*)
Drill M 9
G90 Absolute programming M X 3
G91 Incremental programming M 3
G92
*)
Set actual value memory M 18
G94 Feedrate in mm/min, inch/min M X 5
G95 Feedrate in mm/revolution, inch/ revolution M 5
G98
*)
Return to starting point for fixed cycles M X 10
G99
*)
Return to point R for fixed cycles M 10
G290 Select SIEMENS NC programming language M X 31
G291 Select ISO-Dialekt NC programming language M 31
Subroutine call: Refer to M98
Subroutine end: Refer to M99
*)
These commands are not described in the accompanying document
1)
Initial setting: Refer to details supplied by the machine OEM
2)
M = acts modally; S = acts blockwise
