Technical Appendix
6.1 List of machine and setting data
6-115
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
32910
DYN_MATCH_TIME
- Time constant of dynamic adaption (control parameter set no): 0...5 NEW_CONF
0 0.0 plus DOUBLE 2/7
32920
AC_FILTER_TIME
s Smoothing factor time constant for adaptive control POWER ON
_always 0.0 0.0 plus DOUBLE 2/7
33050
LUBRICATION_DIST
mm, deg. Traversing distance for lubrication from PLC NEW CONF
_always 100000000 0.0 plus DOUBLE 2/7
34000
REFP_CAM_IS_ACTIVE
- Axis with reference point cam RESET
_always 1 *** *** BOOLEAN 2/7
34010
REFP_CAM_DIR_IS_MINUS
- Approach reference point in minus direction RESET
_always 0 *** *** BOOLEAN 2/7
34020
REFP_VELO_SEARCH_CAM
mm/min,
rev/min
Reference point approach velocity RESET
_always 5000.0 0.0 plus DOUBLE 2/7
34030
REFP_MAX_CAM_DIST
mm, deg. Maximum distance to reference cam RESET
_always 10000.0 0.0 plus DOUBLE 2/7
34040
REFP_VELO_SEARCH_MARKER
mm/min,
rev/min
Creep speed (encoder no.) RESET
_always 300.0 0.0 plus DOUBLE 2/7
34050
REFP_SEARCH_MARKER_REVERSE
- Direction reversal to reference cams (encoder no.) RESET
_always 0 *** *** BOOLEAN 2/7
34060
REFP_MAX_MARKER_DIST
mm, deg. Maximum distance to reference mark. Max. distance to 2 reference marks
for distance-coded measuring systems.
RESET
_always 20.0 0.0 plus DOUBLE 2/7
34070
REFP_VELO_POS
mm/min,
rev/min
Reference point positioning velocity RESET
_always 1000.0 0.0 plus DOUBLE 2/7
34080
REFP_MOVE_DIST
mm, deg. Reference point distance/target point for distance-coded system RESET
_always -2.0 - - DOUBLE 2/7
34090
REFP_MOVE_DIST_CORR
mm, deg. Reference point offset/absolute offset distance-coded POWER ON
_always 0.0 - - DOUBLE 2/7
34092
REFP_CAM_SHIFT
mm, deg. Electr. cam offset of incremental measuring systems with equidistant zero marks RESET
_always 0.0 0.0 plus DOUBLE 2/7
34100
REFP_SET_POS
mm, deg. Reference point value/irrelevant for distance-coded system: 0 ... 3 RESET
_always 0., 0., 0., 0. - - DOUBLE 2/7
