Siemens SINUMERIK 802S User Manual

Technical Appendix
6.1 List of machine and setting data
6-116
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
34110
REFP_CYCLE_NR
- Sequence of axes in channel-specific referencing
-1: No obligatory reference point for NC Start
0: No channel-specific reference-point approach
1-15: Sequence in channel-specific reference point approach
RESET
_always 1 -1 31 DWORD 2/7
34200
ENC_REFP_MODE
- Type of position measuring system
0: No ref. point appr.; if an absolute encoder exists: REFP_SET_POS accepted
1: Zero pulse (on encoder track)
2: BERO
3: Distance-coded reference marks
4: Bero with two edges
5. BERO cam
POWER ON
_always 1 0 6 BYTE 2/7
35010
GEAR_STEP_CHANGE_ENABLE
- Gear change possible. Spindle has several gear steps POWER ON
_always 0 *** *** BOOLEAN 2/7
35040
SPIND_ACTIVE_AFTER_RESET
- Own spindle reset POWER ON
_always 0 *** *** BOOLEAN 2/7
35100
SPIND_VELO_LIMIT
rev/min Maximum spindle speed POWER ON
_always 10000 0.0 plus DOUBLE 2/7
35110
GEAR_STEP_MAX_VELO
rev/min Maximum speed for gear change (gear stage no.): 0..5 NEW CONF
_always 500, 500, 1000, 2000, 4000,
8000
0.0 plus DOUBLE 2/7
35120
GEAR_STEP_MIN_VELO
rev/min Minimum speed for gear change (gear stage no.): 0..5 NEW CONF
_always 50, 50, 400, 800, 1500, 3000 0.0 plus DOUBLE 2/7
35130
GEAR_STEP_MAX_VELO_LIMIT
rev/min Maximum speed of gear stage (gear stage no.): 0...5 NEW CONF
_always 500, 500, 1000, 2000, 4000,
8000
0.0 plus DOUBLE 2/7
35140
GEAR_STEP_MIN_VELO_LIMIT
rev/min Minimum speed of gearsetp (gear stage no.): 0...5 NEW CONF
_always 5, 5,10, 20, 40, 80 0.0 plus DOUBLE 2/7
35150
SPIND_DES_VELO_TOL
Factor Spindle speed tolerance RESET
_always 0.1 0.0 1.0 DOUBLE 2/7
35160
SPIND_EXTERN_VELO_LIMIT
rev/min Spindle speed limitation from PLC NEW CONF
_always 1000 0.0 plus DOUBLE 2/7
35200
GEAR_STEP_SPEEDCTRL_ACCEL
rev/s^2 Acceleration in speed control mode [gear stage no.]: 0...5 NEW CONF
_always 30, 30, 25, 20, 15, 10 2 *** DOUBLE 2/7
35210
GEAR_STEP_POSCTRL_ACCEL
rev/s^2 Acceleration in position control mode (gear stage no.): 1...5 NEW CONF
_always 30, 30, 25, 20, 15, 10 2 *** DOUBLE 2/7
35220
ACCEL_REDUCTION_SPEED_POINT
Factor Speed for reduced acceleration RESET
_always 1.0 0.0 1.0 DOUBLE 2/7
