Siemens SINUMERIK 802S User Manual

Technical Appendix
6.1 List of machine and setting data
6-117
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
35230
ACCEL_REDUCTION_FACTOR
Factor Reduced acceleration RESET
_always 0.0 0.0 0.95 DOUBLE 2/7
35240
ACCEL_TYPE_DRIVE
- Type of acceleration RESET
0 0 1 BOOLEAN 2/7
35300
SPIND_POSCTRL_VELO
rev/min Position control switch-on speed NEW CONF
_always 500 0.0 plus DOUBLE 2/7
35350
SPIND_POSITIONING_DIR
- Direction of rotation when positioning RESET
_always 3 3 4 BYTE 2/7
35400 SPIND_OSCILL_DES_VELO
rev/min Reciprocation speed NEW CONF
_always 500 0.0 plus DOUBLE 2/7
35410 SPIND_OSCILL_ACCEL
rev/s^2 Acceleration during reciprocating NEW CONF
_always 16 2 *** DOUBLE 2/7
35430 SPIND_OSCILL_START_DIR
– Starting direction during reciprocation
0–2: As last direction of rotation (zero–speed M3)
3: M3 direction
4: M4 direction
RESET
_always 0 0 4 BYTE 2/7
35440 SPIND_OSCILL_TIME_CW
s Reciprocation time for M3 direction NEW CONF
_always 1.0 0.0 plus DOUBLE 2/7
35450 SPIND_OSCILL_TIME_CCW
s Reciprocation time for M4 direction NEW CONF
_always 0.5 0.0 plus DOUBLE 2/7
35510
SPIND_STOPPED_AT_IPO_START
- Feedrate enable for spindle stopped RESET
_always 0 *** *** BOOLEAN 2/7
36000
STOP_LIMIT_COARSE
mm, deg. Exact positioning coarse NEW CONF
_always 0.04 0.0 plus DOUBLE 2/7
36010
STOP_LIMIT_FINE
mm, deg. Exact positioning fine NEW CONF
_always 0.01 0.0 plus DOUBLE 2/7
36020
POSITIONING_TIME
s Delay exact positioning fine NEW CONF
_always 1.0 0.0 plus DOUBLE 2/7
36030
STANDSTILL_POS_TOL
mm, deg. Zero-speed tolerance NEW CONF
_always 0.2 0.0 plus DOUBLE 2/7
36040
STANDSTILL_DELAY_TIME
s Delay zero-speed monitoring NEW CONF
_always 0.4 0.0 plus DOUBLE 2/7
