Start-Up
4.7 Commissioning
4-98
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
Note
The field containing the parameter “0” is not used for the spindle machine data..
Spindle configuration
Machine data for setpoint and actual values
Setpoints:
MD 30130 CTRLOUT_TYPE [AX4] = 1
Actual values:
MD 30200 NUM_ENCS[AX4] = 0 ;Spindle without encoder
MD 30200 NUM_ENCS[AX4] = 1 ;Spindle with encoder
MD 30240 ENC_TYPE[AX4] = 2
Matching the spindle encoder
Machine data required to match the encoders
Number Description Spindle
31040 Encoder mounted directly to the machine 0 1
31020 Encoder markings per revolution Increments
/rev.
Incr./rev’s
31080 Numerator resolver gearbox Motor rev’s Load rev’s
31070
Denominator resolver gearbox
Encoder
rev’s
Encoder
rev’s
31060 Numerator load gearbox (control parameter set no.): 0...5 Motor rev’s Motor rev’s
31050 Denominator load gearbox (control parameter no.): 0...5 Load rev’s Load rev’s
Example 1 for encoder matching:
Spindle with square–wave encoder (500 pulses) mounted directly on the spindle. The internal
multiplication = 4. The internal computational resolution amounts to 1,000 increments per de-
gree.
MD31020 @ 4
360 degrees
Internal resolution =
MD31070
MD31080
@@
1000
500 @ 4 @ 1
360 @ 1 @ 1000
Internal resolution =
= 180
One encoder increment amounts to 180 internal increments. One encoder increment amounts
to 0.18 degrees (finest positioning possibility).
