Siemens SINUMERIK 804D sl Programming Manual

Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
M19 Spindle positioning to the position entered in
SD43240
+ + PM-NC
M30 End of program, main program (as M2) + + PM-NC
M40 Automatic gear change + + PM-NC
M41 ... M45 Gear stage 1 ... 5 + + PM-NC
M70 Transition to axis mode + + PM-NC
MASLDEF P Define master/slave axis grouping + + PM-NC
MASLDEL P Uncouple master/slave axis grouping and
clear grouping definition
+ + PM-NC
MASLOF P Deactivation of a temporary coupling + + PM-NC
MASLOFS P Deactivation of a temporary coupling with au‐
tomatic slave axis stop
+ + PM-NC
MASLON P Activation of a temporary coupling + + PM-NC
MATCH F Search for string in string + - PM-NC
MAXVAL F Larger value of two variables (arithm. function) + + PM-NC
MCALL K Modal subprogram call + PM-NC
MEAC K Continuous axial measurement without delete
distance-to-go
s + + PM-NC
MEAFRAME F Frame calculation from measuring points + - PM-NC
MEAS A Measurement with deletion of distance-to-go s + PM-NC
MEASA K Axial measurement with delete distance-to-go s + + PM-NC
MEASURE F Calculation method for workpiece and tool
measurement
+ - FM-TE
MEAW A Measurement without delete distance-to-go s + PM-NC
MEAWA K Axial measurement without delete distance-to-
go
s + + PM-NC
MI K Access to frame data: Mirroring + PM-NC
MINDEX F Define index of character in input string + - PM-NC
MINVAL F Smaller value of two variables (arithm. func‐
tion)
+ + PM-NC
MIRROR G Programmable mirroring s + PM-NC
MMC P Call the dialog window interactively from the
part program on the HMI
+ - PM-NC
MOD K Modulo division + PM-NC
MODAXVAL F Determine modulo position of a modulo rotary
axis
+ - PM-NC
MOV K Start positioning axis - + FM-SA
MOVT A Specify end point of a traversing motion in the
tool direction
FM-B
MSG P Programmable messages m + - PM-NC
MVTOOL P Language command to move tool + - FM-TM
N A NC auxiliary block number + PM-NC
NAMETOINT F Determining the system variable index + PM-NC
Tables
4.1 Operations
NC programming
1220 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
