Siemens SINUMERIK 804D sl Programming Manual

Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
NC K Specify validity range for data + PM-NC
NEWCONF P Apply modified machine data (corresponds to
"Activate machine data")
+ - PM-NC
NEWMT F Create new multitool + - FM-TM
NEWT F Create new tool + - FM-TM
NORM
6)
G Standard setting in starting point and end
point with tool offset
m + PM-NC
NOT K Logic NOT (negation) + PM-NC
NPROT P Machine-specific protection area ON/OFF + - PM-NC
NPROTDEF P Definition of a machine-specific protection
area
+ - PM-NC
NUMBER F Convert input string to number + - PM-NC
OEMIPO1 G OEM interpolation 1 m + PM-NC
OEMIPO2 G OEM interpolation 2 m + PM-NC
OF K Keyword in CASE branch + PM-NC
OFFN A Allowance on the programmed contour m + PM-NC
OMA1 A OEM address 1 m + PM-NC
OMA2 A OEM address 2 m + PM-NC
OMA3 A OEM address 3 m + PM-NC
OMA4 A OEM address 4 m + PM-NC
OMA5 A OEM address 5 m + PM-NC
OR K Logic operator, OR operation + PM-NC
ORIAXES G Linear interpolation of machine axes or orien‐
tation axes
m + PM-NC
ORIAXPOS G Orientation angle via virtual orientation axes
with rotary axis positions
m + PM-NC
ORIC
6)
G Orientation changes at outside corners are
superimposed on the circle block to be inser‐
ted
m + PM-NC
ORICONCCW G Interpolation on a circular peripheral surface
in CCW direction
m + PM-NC, FM-TR
ORICONCW G Interpolation on a circular peripheral surface
in CW direction
m + PM-NC, FM-TR
ORICONIO G Interpolation on a circular peripheral surface
with intermediate orientation setting
m + PM-NC, FM-TR
ORICONTO G Interpolation on circular peripheral surface in
tangential transition
(final orientation)
m + PM-NC, FM-TR
ORICURVE G Interpolation of orientation with specification
of motion of two contact points of tool
m + PM-NC, FM-TR
ORID G Orientation changes are performed before the
circle block
m + PM-NC
ORIEULER
6)
G Orientation angle via Euler angle m + PM-NC
Tables
4.1 Operations
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1221
