Page #104 background imageLoading...
Page #104 background image
808d-te62 - 0 0 100 0/0
808d-mte40 - 0 0 100 7/2
808d-mte60 - 0 0 100 7/2
Description: Number of global predefined user frames.
The value corresponds to the number of field elements for the predefined field
$P_UIFR[].
If the value of the data is greater than 0, then all settable fields are only global.
The MD28080 $MC_MM_NUM_USER_FRAMES is then ignored.
18602 MM_NUM_GLOBAL_BASE_FRAMES N02 K2, M5
- Number of global base frames (SRAM). DWORD PowerOn
-
808d-me42 - 0 0 16 0/0
808d-me62 - 0 0 16 0/0
808d-te42 - 0 0 16 0/0
808d-te62 - 0 0 16 0/0
808d-mte40 - 0 0 16 7/2
808d-mte60 - 0 0 16 7/2
Description: Number of NCU basic frames.
The value corresponds to the number for the predefined field $P_NCBFR[].
18603 MM_NUM_GLOBAL_G_FRAMES N02 K2, M5
- Number of global grinding frames (SRAM) DWORD PowerOn
-
808d-me42 - 0 0 100 0/0
808d-me62 - 0 0 100 0/0
808d-te42 - 0 0 100 0/0
808d-te62 - 0 0 100 0/0
808d-mte40 - 0 0 100 7/2
808d-mte60 - 0 0 100 7/2
Description: Number of global grinding frames.
The value corresponds to the number of field elements for the predefined field
$P_GFR[].
If the value of the data is greater than 0, all settable frames are only global.
MD28079 $MC_MM_NUM_G_FRAMES is then ignored.
18660 MM_NUM_SYNACT_GUD_REAL N02 -
- Number of configurable GUD variables of type REAL DWORD PowerOn
-
808d-me42 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0
808d-me62 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0
808d-te42 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0
808d-te62 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0
808d-mte40 9 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 7/2
808d-mte60 9 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 7/2
Description: The MD18660 $MN_MM_NUM_SYNACT_GUD_REAL[ ] can be used to extend individual GUD blocks
by additional channel-specific parameter areas of type REAL. The GUD blocks are
differentiated by the field index:
MD18660 $MN_MM_NUM_SYNACT_GUD_REAL[0] = <value> -> extension of the SGUD block
Machine data
3.2 General machine data
Parameter Manual
104 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
