MD20060 $MC_AXCONF_GEOAX_NAME_TAB[n] must be specified.
If space characters are entered or if an axis identifier is specified for an axis which
is not defined as a geometry axis, this leads to the following alarms:
● during
runup,
to
alarm 4032 "Channel %1 wrong identifier for transverse axis in %2",
if the "Diameter programming" function (DIAMON) or constant cutting velocity G96/
G961/G962 is the switch-on setting.
● when the "Diameter programming (DIAMON)" function is activated, to alarm 16510
"Channel %1 block %2 No transverse axis available for diameter programming", if no
axis has been permitted via DIAMCHANA[AX] for channel-specific diameter programming.
● when G96/G961/G962 has been programmed, to alarm 10870 "Channel %1 block %2 No
transverse axis defined as reference axis for G96/G961/G962", if no geometry axis
has been defined as the reference axis for G96/G961/G962 by the instruction SCC[ax].
Related to:
MD20060 $MC_AXCONF_GEOAX_NAME_TAB[n]
MD24120 $MC_TRAFO_AX_GEOAX_ASSIGN_TAB_1[n]
MD30460 $MA_BASE_FUNCTION_MASK
20105 PROG_EVENT_IGN_REFP_LOCK N01 K1, Z1
- Start Prog-Events despite non-referenced axes. DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3F 2/2 M
Description: The behavior of event-driven program calls (prog-events) regarding non-referenced axes
can be set.
Bit 0 = 1 :
Prog-event ignores non-referenced axes after part program start
Bit 1 = 1 :
Prog-event after part program end ignores non-referenced axes
Bit 2 = 1 :
Prog-event after operator panel reset ignores non-referenced axes
Bit 3 = 1 :
Prog-event after power-up ignores non-referenced axes
Bit 4 = 1 :
Prog-event after 1st start after search ignores non-referenced axes
Bit 5 = 1 :
Reserved
Corresponds with:
MD20106 $MC_PROG_EVENT_IGN_SINGLEBLOCK
MD20107 $MC_PROG_EVENT_IGN_INHIBIT
MD20108 $MC_PROG_EVENT_MASK
MD20192 $MC_PROG_EVENT_IGN_PROG_STATE
MD20193 $MC_PROG_EVENT_IGN_STOP
The machine data MD20105 $MC_PROG_EVENT_IGN_REFP_LOCK and MD20115
$MC_IGNORE_REFP_LOCK_ASUP replace bit 1 from MD11602 $MN_ASUP_START_MASK.
If MD20700 $MC_REFP_NC_START_LOCK is equal to 0, the setting in MD20105
$MC_PROG_EVENT_IGN_REFP_LOCK is ignored, and non-referenced axes are always ignored.
20106 PROG_EVENT_IGN_SINGLEBLOCK N01 K1, Z1
- Prog-Events ignore single block DWORD PowerOn
-
808d-me42 - 0x1F 0 0x3F 2/2 M
Machine data
3.3 Channel-specific machine data
Parameter Manual
116 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
