808d-me62 - 0x1F 0 0x3F 2/2 M
808d-te42 - 0x1F 0 0x3F 2/2 M
808d-te62 - 0x1F 0 0x3F 2/2 M
808d-mte40 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3F 2/2 M
808d-mte60 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3F 2/2 M
Description: Event-driven program calls (Prog-Events) can be set regarding their single-block
response.
Bit 0 = 1 :
Prog-Event after start-of-part-program causes block change without restart
Bit 1 = 1 :
Prog-Event after end-of-part-program causes block change without restart
Bit 2 = 1 :
Prog-Event after OP reset causes block change without restart
Bit 3 = 1 :
Prog-Event after ramp-up causes block change without restart
Bit 4 = 1 :
Prog-Event after 1st start after search causes block change without restart
Bit 5 = 1 :
Safety Prog-Event during ramp-up causes block change without restart
Corresponds to:
MD20105 $MC_PROG_EVENT_IGN_REFP_LOCK
MD20107 $MC_PROG_EVENT_IGN_INHIBIT
MD20108 $MC_PROG_EVENT_MASK
MD20192 $MC_PROG_EVENT_IGN_PROG_STATE
MD20193 $MC_PROG_EVENT_IGN_STOP
20107 PROG_EVENT_IGN_INHIBIT N01 K1, Z1
- Prog-Events ignore read-in disable DWORD PowerOn
-
808d-me42 - 0x0C 0 0x3F 2/2 M
808d-me62 - 0x0C 0 0x3F 2/2 M
808d-te42 - 0x0C 0 0x3F 2/2 M
808d-te62 - 0x0C 0 0x3F 2/2 M
808d-mte40 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3F 2/2 M
808d-mte60 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3F 2/2 M
Description: Event-driven programm calls (Prog-Events) can be set regarding their read-in disable
response.
Bit 0 = 1 :
Prog-Event after start-of-part-program causes block change despite read-in disable
Bit 1 = 1 :
Prog-Event after end-of-part-program causes block change despite read-in disable
Bit 2 = 1 :
Prog-Event after OP reset causes block change despite read-in disable
Bit 3 = 1 :
Prog-Event after ramp-up causes block change despite read-in disable
Bit 4 = 1 :
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 117
