Page #126 background imageLoading...
Page #126 background image
Bit 16 = 0:
The current setting of the master spindle (SETMS) is retained.
Bit 16 = 1:
Initial setting for the master spindle according to MD20090 $MC_SPIND_DEF_MASTER_SPIND
Bit 17 = 0:
The current setting of the master toolholder (SETMTH) is retained (relevant only if
tool or magazine management is active)
Bit 17 = 1:
Only if MD20124 $MC_TOOL_MANAGEMENT_TOOLHOLDER> 0: Inital setting for the master
toolholder according to MD20124 $MC_TOOL_MANAGEMENT_TOOLHOLDER.
Otherwise, the setting for the master spindle applies.
Bit 18 = 0:
Reference axis for G96/G961/G962 according to MD20100 $MC_DIAMETER_AX_DEF.
When using SCC with its own spindle reset, setting bit 18 = 1 is recommended (see also
MD20110: $MC_RESET_MODE_MASK, bit 18).
Bit 18 = 1:
Reference axis for G96/G961/G962 is retained.
Related to:
MD20120 $MC_TOOL_RESET_VALUE
MD20130 $MC_CUTTING_EDGE_RESET_VALUE
MD20150 $MC_GCODE_RESET_VALUES
MD20152 $MC_GCODE_RESET_MODE
MD20110 $MC_RESET_MODE_MASK
MD20121 $MC_TOOL_PRESEL_RESET_VALUE
20114 MODESWITCH_MASK C03 K1
- Interruption MDI by mode change DWORD Reset
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0xFFFF 1/1 M
Description: After program interruption in MDI mode (e.g. in order to carry out a measurement on
the workpiece and
to correct the tool wear values or after tool breakage) the tool can
be manually withdrawn from the contour by changing into JOG mode.
In this case, the control stores the coordinates of the position of the interruption
and indicates the
path differences traversed by the axes in JOG mode as "Repos offset".
When MDI mode is selected again, the axis is repositioned on the contour. This response
can be canceled by means of this machine data.
Bit 0 (LSB)= 0:
When MDI (JOG, JOGREF, JOGREPOS, MDIREF and MDIREPOS) are deselected in stopped
status, the system ASUB Repos is selected.
Bit 0 (LSB) = 1:
When MDI (JOG, JOGREF, JOGREPOS, MDIREF and MDIREPOS) are deselected in stopped
status, the system ASUB Repos is not selected.
Bit 1 (LSB) = 0:
If the NCK stops at a part program block in the program execution in which
repositioning
is not possible, alarm 16916 is generated if an attempt is made to switch
to manual mode.
Bit 1 (LSB) = 1:
If the NCK stops at a part program block in the program execution in which
repositioning is not possible, no alarm is generated if an attempt is made to switch
to manual mode.
Machine data
3.3 Channel-specific machine data
Parameter Manual
126 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
