Siemens SINUMERIK 808D ADVANCED Parameter Manual

20115 IGNORE_REFP_LOCK_ASUP C01 K1, Z1
- Process interrupt program despite non-referenced axes DWORD NEW CONF
-
- - 0x200, 0x200, 0x200,
0x200, 0x200, 0x200,
0x200, 0x200...
0 0x7FFFFFFF 2/2 M
Description: Despite non-referenced axes, an assigned user ASUB is processed for the interrupt
whose bit is set.
Bit 0 is assigned to interrupt 1.
Bit 1 is assigned to interrupt channel 2, etc.
Corresponds to:
MD11602 $MN_ASUP_START_MASK
MD20116 $MC_IGNORE_INHIBIT_ASUP
MD20117 $MC_IGNORE_SINGLEBLOCK_ASUP
MD20191 $MC_IGN_PROG_STATE_ASUP
MD20194 $MC_IGNORE_NONCSTART_ASUP
The machine data MD20105 $MC_PROG_EVENT_IGN_REFP_LOCK and MD20115
$MC_IGNORE_REFP_LOCK_ASUP replace bit 1 from MD11602 $MN_ASUP_START_MASK.
If MD20700 $MC_REFP_NC_START_LOCK is equal to 0, the setting in MD20105
$MC_PROG_EVENT_IGN_REFP_LOCK will be ignored.
20116 IGNORE_INHIBIT_ASUP C01 K1, Z1
- Execute interrupt program despite read-in disable DWORD NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7FFFFFFF 2/2 M
Description: In spite of the set read-in disable, an assigned user ASUB is completely executed for
the interrupt channel with the set bit.
Bit 0 is assigned to interrupt channel 1.
Bit 1 is assigned to interrupt channel 2, etc.
Related to:
MD11602 $MN_ASUP_START_MASK
MD20115 $MC_IGNORE_REFP_LOCK_ASUP
MD20117 $MC_IGNORE_SINGLEBLOCK_ASUP
MD20191 $MC_IGN_PROG_STATE_ASUP
MD20194 $MC_IGNORE_NONCSTART_ASUP
20117 IGNORE_SINGLEBLOCK_ASUP C01 K1, Z1
- Execute interrupt program completely despite single block DWORD NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7FFFFFFF 2/2 M
Description: In spite of the set single-block processing mode, an assigned user ASUB is completely
executed for the relevant channel with the set bit.
Bit 0 is assigned to interrupt channel 1.
Bit 1 is assigned to interrupt channel 2, etc.
The MD is only active with single block type 1.
Related to:
MD11602 $MN_ASUP_START_MASK
MD20115 $MC_IGNORE_REFP_LOCK_ASUP
MD20116 $MC_IGNORE_INHIBIT_ASUP
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 127
