MD20191 $MC_IGN_PROG_STATE_ASUP
MD20194 $MC_IGNORE_NONCSTART_ASUP
20120 TOOL_RESET_VALUE C03 K1, W1
- Tool with length compens. during runup (reset/part program end). DWORD Reset
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 32000 1/1 M
Description: Definition of the tool for which tool length compensation is selected during runup or
on reset or
part program end as a function of MD20110 $MC_RESET_MODE_MASK, and on part
program start as a function of MD20112 $MC_START_MODE_MASK
Related to:
MD20110 $MC_RESET_MODE_MASK
MD20112 $MC_START_MODE_MASK
20121 TOOL_PRESEL_RESET_VALUE C03 K1, W1
- Preselected tool on RESET DWORD Reset
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 32000 1/1 M
Description: Definition of the preselected tool in MD20310 $MC_TOOL_MANAGEMENT_MASK=1.
A tool is selected after runup, or on reset or part program end as a function of
MD20110 $MC_RESET_MODE_MASK, and on part program start as a function of MD20112
$MC_START_MODE_MASK.
This MD is valid only without tool management.
Related to:
MD20110 $MC_RESET_MODE_MASK
MD20112 $MC_START_MODE_MASK
20130 CUTTING_EDGE_RESET_VALUE C03 -
- Tool edge with length compens. during runup (reset/end of pp) DWORD Reset
-
808d-me42 - 1, 1, 1, 1, 1, 1, 1, 1... 0 32000 1/1 M
808d-me62 - 1, 1, 1, 1, 1, 1, 1, 1... 0 32000 1/1 M
808d-te42 - 1, 1, 1, 1, 1, 1, 1, 1... 0 32000 1/1 M
808d-te62 - 1, 1, 1, 1, 1, 1, 1, 1... 0 32000 1/1 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 32000 1/1 M
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 32000 1/1 M
Description: Definition of the cutting edge for which tool length compensation is selected during
runup or on reset or part program end as a function of MD20110 $MC_RESET_MODE_MASK,
and as a function of MD20112 $MC_START_MODE_MASK on part program start.
With active tool management and with bit 0 and bit 6 set in MD20110 $MC_RESET_MODE_MASK
at selection, the
last offset of the tool active at power OFF - as a rule the tool on
the spindle - is effective after runup.
Related to:
MD20110 $MC_RESET_MODE_MASK
MD20112 $MC_START_MODE_MASK
20132 SUMCORR_RESET_VALUE C03 -
- Effective resulting offset on RESET DWORD Reset
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 6 7/2 M
Machine data
3.3 Channel-specific machine data
Parameter Manual
128 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
