Siemens SINUMERIK 808D ADVANCED Parameter Manual

808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 6 7/2 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 6 7/2 M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 6 7/2 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 6 0/0 S
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 6 0/0 S
Description: Definition of the total offset with which the tool length compensation is selected in
the runup and
on reset or part program end as a function of MD20110 $MC_RESET_MODE_MASK
and as a function of MD20112 $MC_START_MODE_MASK on part program start.
MD18110 $MN_MM_MAX_SUMCORR_PER_CUTTEDGE determines the maximum useful value which can
be entered.
20150 GCODE_RESET_VALUES C11, C03 F2, TE4, K3, M1, M5, K1, K2, P1,
V1
- Initial setting of G groups BYTE Reset
-
808d-me42 70 2, 0, 0, 1, 0, 1, 1, 1, 0,
2, 0, 1, 4, 1, 2, 1, 1, 1,
1, 1, 2,
0 - 1/1 M
808d-me62 70 2, 0, 0, 1, 0, 1, 1, 1, 0,
2, 0, 1, 4, 1, 2, 1, 1, 1,
1, 1, 2,
0 - 1/1 M
808d-te42 70 2, 0, 0, 1, 0, 2, 1, 1, 0,
2, 0, 1, 4, 1, 3, 1, 1, 1,
1, 1, 2,
0 - 1/1 M
808d-te62 70 2, 0, 0, 1, 0, 2, 1, 1, 0,
2, 0, 1, 4, 1, 3, 1, 1, 1,
1, 1, 2,
0 - 1/1 M
808d-mte40 70 2, 0, 0, 1, 0, 1, 1, 1, 0,
1, 0, 1, 2, 1, 2, 1, 1, 1,
1, 1, 1,, ...
0 - 1/1 M
808d-mte60 70 2, 0, 0, 1, 0, 1, 1, 1, 0,
1, 0, 1, 2, 1, 2, 1, 1, 1,
1, 1, 1,, ...
0 - 1/1 M
Description: Definition of the G codes, which are active when powering up and reset and/or end of
part program depending on MD20152 $MC_GCODE_RESET_MODE and for the start of part
program depending on MD20112 $MC_START_MODE_MASK.
The index of the G codes in the respective groups must be programmed as the default
value.
For a list of the G groups and their G functions, please refer to References:
Programming Manual, Fundamentals
Designation Group Standard value for 840D
GCODE_RESET_VALUES[0] 1 2 (G1)
GCODE_RESET_VALUES[1] 2 0 (inactive)
GCODE_RESET_VALUES[2] 3 0 (inactive)
GCODE_RESET_VALUES[3] 4 2 (STARTFIFO)
GCODE_RESET_VALUES[4] 5 0 (inactive)
GCODE_RESET_VALUES[5] 6 1 (G17)
GCODE_RESET_VALUES[6] 7 1 (G40)
GCODE_RESET_VALUES[7] 8 1 (G500)
GCODE_RESET_VALUES[8] 9 0 (inactive)
GCODE_RESET_VALUES[9] 10 1 (G60)
GCODE_RESET_VALUES[10] 11 0 (inactive)
GCODE_RESET_VALUES[11] 12 1 (G601)
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 129
