Bit 19, in conjunction with set bits 5, 6, 7, 8, delays block processng.
Bit 19=0: The synchronizations determined by bits 5...8 refer to the tool command
output. This means that the block change is not delayed.
Bit 20 to bit 24
Bit 20=0: If the PLC signal "Program test active" is present, then the commands
generated are not output to the PLC. The NCK acknowledges the commands itself. The
magazine and tool data are not changed.
Bit 20=1: If the PLC signal "Program test active" is present, then the commands
generated are output to the PLC. Depending upon the type of acknowledgment, tool/
magazine data can be changed in the NCK. If the acknowledgment parameters for the
"target
magazine" are
given the values of the "source magazine", then there is no tool
transport, and thus also no data change in the NCK.
Bit 21=0: Default setting: Ignore the tool state "W" during tool selection.
Bit 21=1: Tools in the state "W" cannot be selected by another tool change/tool
preparation command.
Bit 22=1: Function "Tool subgroups"
$TC_TP11[x] is the grouping or selection parameter
Bit 23=0: Default setting
The tool management selects the tool optimally and safely in the main run. This means
that the interpreter may have to wait until the end of the tool selection for the
offset selection.
Bit 23=1: For simple applications
The interpreter selects the tool itself. This means synchronization with the main run
is not required for the offset selection. (However, an uncorrectable alarm may be
issued if a tool becomes unserviceable after selection but before loading.)
Bit 24=0: Default setting
If the PLC commands 8 and 9 (asynchronous transfer) want to move a tool to a location
reserved for another tool, then this is rejected with an alarm.
Bit 24=1: If the PLC commands 8 and 9 want to move a tool to a location reserved for
another tool with "Reserved for tool from buffer" (bit value= "H4"), then this is
possible. This location reservation is removed before execution of the motion
("Reserved for new tool to be loaded" (bit value= "H8") remains effective).
Related to:
MD18080 $MN_MM_TOOL_MANAGEMENT_MASK
MD20320 $MC_TOOL_TIME_MONITOR_MASK
MD20122 $MC_TOOL_RESET_NAME
MD20110 $MC_RESET_MODE_MASK
MD20124 $MC_TOOL_MANAGEMENT_TOOLHOLDER
MD22560 $MC_TOOL_CHANGE_M_CODE
20360 TOOL_PARAMETER_DEF_MASK C09 M5, P1, W1
- Definition of tool parameters DWORD PowerOn
-
808d-me42 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3FFFFF 1/1 M
808d-me62 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3FFFFF 1/1 M
808d-te42 - 0x283 0 0x3FFFFF 1/1 M
808d-te62 - 0x283 0 0x3FFFFF 1/1 M
808d-mte40 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3FFFFF 1/1 M
808d-mte60 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3FFFFF 1/1 M
Machine data
3.3 Channel-specific machine data
Parameter Manual
142 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
